Union 2234E 5-Lever BS Mortice Sashlock - Polished Brass Finish - 3" (79.5mm) Case

Summary

The Union 2234E is a 5-lever British Standard mortice sashlock in a polished brass finish, designed for timber entrance doors hinged on the left or right. Kitemarked to BS3621:2007 and approved under the police Secured by Design initiative, it provides insurance-approved high security for residential and commercial properties. Supplied in visipak packaging complete with three keys.

Features

• Five-lever mechanism provides high-security operation, recommended and approved by insurance companies.
• Kitemarked to BS3621:2007 and approved by the police Secured by Design initiative.
• 20mm anti-saw deadbolt with hardened steel rollers delivers positive deadlocking and strong resistance to forced entry.
• Anti-pick, anti-saw and anti-drill security features throughout for comprehensive attack resistance.
• Chamfered bolt design increases performance under side-load testing and makes drilling attack more difficult.
• Pierced casing accepts bolt-through door furniture for versatile handle fitting.
• Covered escutcheon supplied, finished to match the polished brass forend.
• Suitable for timber doors up to 54mm thick, reversible for left- or right-hand hinging.
• Covered by a 15-year manufacturer's guarantee.

Specifications

• Levers: 5
• Case Size: 79.5 x 111mm (3")
• Backset: 57.5mm
• Centre (follower to keyhole): 57mm
• Deadbolt Throw: 20mm
• Forend Finish: Polished Brass
• Max Door Thickness: 54mm
• Standard: BS3621:2007 (Kitemarked)
• SKU / MPN: Y2234E-PL-3.00

What's Included

• 1 x Union 2234E 5-Lever BS Mortice Sashlock - Polished Brass, 3" Case
• 3 x Steel nickel-plated keys
• Covered escutcheon (matched to forend)
• Security box-type striking plate (brass finish)
• Fixing screws
